Ultimate molecular dynamic simulation build

the_matrix_333
By the_matrix_333
in New Builds and Planning
 Share
Posted

Hi, I am looking for a workstation for molecular dynamic simulation work using gromacs (http://www.gromacs.org/) but I am not an expert in building computer, what would you guy recommend for this kind of work? no budget constrains

Link to comment
Share on other sites
Link to post
Share on other sites
Posted
2 minutes ago, the_matrix_333 said:

Hi, I am looking for a workstation for molecular dynamic simulation work using gromacs (http://www.gromacs.org/) but I am not an expert in building computer, what would you guy recommend for this kind of work? no budget constrains

we can go as high as you can go (30k$+)

so please give us a budget

Dutch Talk Thread

Unofficial LMG Social Media Accounts Website

Link to comment
Share on other sites
Link to post
Share on other sites
Posted
  • Author

around 8.5k$,

also you can give the ultimate machine with no budget constrain is case got grants from somewhere

FYI; I heard gromacs optimised for CUDA and work better with single socket cpu board

Link to comment
Share on other sites
Link to post
Share on other sites
Posted
5 minutes ago, the_matrix_333 said:

around 8.5k$,

also you can give the ultimate machine with no budget constrain is case got grants from somewhere

FYI; I heard gromacs optimised for CUDA and work better with single socket cpu board

something like this guy is building maby?:



I spent $2500 on building my PC and all i do with it is play no games atm & watch anime at 1080p(finally) watch YT and write essays...  nothing, it just sits there collecting dust...

Builds:

The Toaster Project! Northern Bee!



The original LAN PC build log! (Old, dead and replaced by The Toaster Project & 5.0)

Spoiler

"Here is some advice that might have gotten lost somewhere along the way in your life.



#1. Treat others as you would like to be treated.

#2. It's best to keep your mouth shut; and appear to be stupid, rather than open it and remove all doubt.

#3. There is nothing "wrong" with being wrong. Learning from a mistake can be more valuable than not making one in the first place.



Follow these simple rules in life, and I promise you, things magically get easier. " - MageTank 31-10-2016





Link to comment
Share on other sites
Link to post
Share on other sites
Posted
  • Author

I think it should be a single good cpu with a bunch of graphic cards I need GPU power the most and it have to run for a long time(like a week or month) in 100% utilisation for a single simulation, so heat management is another serious issue

Link to comment
Share on other sites
Link to post
Share on other sites
Posted
25 minutes ago, the_matrix_333 said:

I think it should be a single good cpu with a bunch of graphic cards I need GPU power the most and it have to run for a long time(like a week or month) in 100% utilisation for a single simulation, so heat management is another serious issue

PCPartPicker part list / Price breakdown by merchant

CPU: Intel Xeon E5-2640 V3 2.6GHz 8-Core Processor  ($909.99 @ SuperBiiz)
CPU: Intel Xeon E5-2640 V3 2.6GHz 8-Core Processor  ($909.99 @ SuperBiiz)
CPU Cooler: Noctua NH-U14S 55.0 CFM CPU Cooler  ($69.95 @ Amazon)
CPU Cooler: Noctua NH-U14S 55.0 CFM CPU Cooler  ($69.95 @ Amazon)
Motherboard: Asus Z10PE-D8 WS SSI EEB Dual-CPU LGA2011-3 Motherboard  ($548.99 @ SuperBiiz)
Memory: Kingston 64GB (4 x 16GB) Registered DDR4-2133 Memory  ($387.99 @ SuperBiiz)
Memory: Kingston 64GB (4 x 16GB) Registered DDR4-2133 Memory  ($387.99 @ SuperBiiz)
Storage: Crucial MX200 1TB 2.5" Solid State Drive  ($316.57 @ Adorama)
Video Card: Zotac GeForce GTX 980 Ti 6GB Video Card (4-Way SLI)  ($609.99 @ Amazon)
Video Card: Zotac GeForce GTX 980 Ti 6GB Video Card (4-Way SLI)  ($609.99 @ Amazon)
Video Card: Zotac GeForce GTX 980 Ti 6GB Video Card (4-Way SLI)  ($609.99 @ Amazon)
Video Card: Zotac GeForce GTX 980 Ti 6GB Video Card (4-Way SLI)  ($609.99 @ Amazon)
Case: Phanteks Enthoo Series Primo Aluminum ATX Full Tower Case  ($209.99 @ Newegg)
Power Supply: EVGA SuperNOVA T2 1600W 80+ Titanium Certified Fully-Modular ATX Power Supply  ($393.49 @ SuperBiiz)
9x Case Fan: Noctua NF-A14 industrialPPC-3000 PWM 158.5 CFM 140mm  Fan  ($26.98 @ OutletPC)

Total: $6887.68
Prices include shipping, taxes, and discounts when available
Generated by PCPartPicker 2016-02-21 06:58 EST-0500



Took some inspiration from this site: http://exxactcorp.com/index.php/solution/solu_detail/121



Also, extra cores seem to help.
