i need a screw...

[Duluxdoggy]

hi, i want to do a small mod to my chair, gonna lower the arms a bit, to do this im going to un bolt the arms from the underside of the chair, place a block of mdf, and use longer bolts, so i ordered some 80mm m6 bolts, but the thread pitch is different, im not an engineer and dont know what to order next, here is a pic of em side by side, the one on the right is the thread i need, the one on the left is m6x1.0.

[megadarkwood]

To the hardware store!

[Hans Christian | Teri]

Yep, your local hardware store is your best bed.

[megadarkwood]

Yep, your local hardware store is your best bed.

It wouldn't really be that comfortable to sleep on a hardware store

[M-ursu]

It wouldn't really be that comfortable to sleep on a hardware store

[megadarkwood]


He made a typo and said "Bed"

[M-ursu]

He made a typo and said "Bed"

[TymmVonD]

Or Auto Part store. Most of them will have a thread template. You thread your fastener into the template and it confirms your thread type. They also sell spacers instead of using mdf/plywood. Can be of more convenience than walking through a big box hardware store.

[megadarkwood]


[M-ursu]

CoolBeans

[Bonsai99]

CoolBeans

[M-ursu]

@CoolBeans

[Hans Christian | Teri]

It wouldn't really be that comfortable to sleep on a hardware store



Hahahaha. I must've been half asleep when I wrote that.

[Duluxdoggy]

OH WELL, NEED TO SHOPPING FOR SOME PAINT TOMORROW ANYWAY. JUST THOUGHT SOMEONE MAY OF HAD AN INCLIN





EDIT: oops, caps lock ftw

[ofr057]

My guess is that there imperial - easy way to check is the size socket that fits on it.



having a stab i would say its a 1/4 inch coarse thread



here's some links to help

http://www.boltdepot.com/fastener-information/Printable-Tools/US-Hex-Bolt-Sizes.pdf

http://www.boltdepot.com/fastener-information/Printable-Tools/Metric-Hex-Bolt-Sizes.pdf

[ofr057]

OH WELL, NEED TO SHOPPING FOR SOME PAINT TOMORROW ANYWAY. JUST THOUGHT SOMEONE MAY OF HAD AN INCLIN





EDIT: oops, caps lock ftw

check what i said above

[Duluxdoggy]

check what i said above

sorry, i failed to check for updates, didnt notice your post, i went to a local hardware store (b&q) but they only stock metric, and i cant go off the had size as they are hex key bolts, i will take a shot and your estimate and order some qtr inch.

[Duluxdoggy]

these are a few close ups next to a good ruler,

[ofr057]

these are a few close ups next to a good ruler,

those photos dont really help , the upper right has a shadow on it but measure the thickness

http://mdmetric.com/tech/cvtcht.htm
