Graphical Glitches - GTX 970

[CraveNinja]

Hi guys so me and my brother tried installing the Accelero Twin Turbo III for the GTX 970 since his fans didn't work. Since installing them  we have been getting graphical glitches white lines all over the screen and also it doesn't boot to Windows. If there is a way to fix this we would really appreciate your help thanks

Edited December 27, 2019 by CraveNinja
I also took this picture after the installation. I wanted to see if everything is alright.

[RainingTacco]

Temperatures? VRM/Memory/Core?

Edit: nvm it doesn't even boot to windows. Have you tried to boot it into safe mode, or safe mode with low resolution? It looks like the connection between the die/memory and cooler is faulty and it overheats in a minute.Make sure that not only die is covered but also memory chips[ive checked how the cooler looks, it doesn't have any element that would touch the memory modules, maybe it needs some thermal pads?]. Or you broken some SMD elements on the PCB, or maybe the fan is installed incorrectly in the header? Do cooler in any way affect the clearance of the video connectors? Maybe they are not pushing enough?

[CraveNinja]

how can i check the temperatures since i cant boot into windows?

[RainingTacco]

1 minute ago, CraveNinja said:

how can i check the temperatures since i cant boot into windows?

I have a pyrometer at my workplace :D, nvm ive updated the post.

[CraveNinja]

thanks for the reply ill try those methods



[CraveNinja]

Hi i just edited the post and added an image of the graphics card after installation since i wanted to see if everything's alright. Do you see anything that might look wrong or broken?

[CraveNinja]

Sorry for the image quality



[Whiro]

5 minutes ago, CraveNinja said:

Sorry for the image quality



Quality of that pic is really low, can’t say if something is broken or not.
I know the og cooler fans wasn’t working but you can try mounting it and see if it boots with it.

Also if your cpu have igpu try connecting monitor to mobo and see if that boots, at least it will eliminate if there is other problems or if its gpu

[CraveNinja]

ok thanks i'll try the old cooler.

[CraveNinja]

well i tried all of the things and it seems like its the gpu since even with the other fans i still have the graphical errors and wasnt booting and also with the hdmi plugged into the motherboard using IGPU i was able to boot into windows.
