Building a new pc... does this look right?

[SeaPanda]

What's up guys,

So I'm installing my cpu fan right now and the brackets don't look right... it's a Asus z97-A board and the cpu cooler is a cooler Master hyper t4. The picture is below. Thanks in advance.

[TheRandomness]

What picture?

[SeaPanda]

What picture?

It didn't add the first time...

[Ajido]

For socket 1150, aren't you supposed to use the center threading for all the screws? It seems off.

[SeaPanda]

For socket 1150, aren't you supposed to use the center threading for all the screws? It seems off.

Oh okay, the instruction were a tad in clear thanks.

[Sir_Chicken]

Z97 has a LGA 1150 socket.

(scoket = where the cpu goes)



CM Hyper T4 can be mounted on the following sockets:

• Socket 1155
• Socket 1156
• Socket 1366
• Socket 2011
• Socket 775
• Socket AM2
• Socket AM3
• Socket AM3+
• Socket FM1



LGA 1155 has the same mounting mechanics as LGA 1150
