AMD Ryzen 7 5800X 8-core, 16-Thread Unlocked Desktop Processor, in thiss case? (Not built yet). Just for fun.

[Edward78]

Will it have enough cooling in https://www.amazon.com/gp/product/B0BLXY7S4Y/ref=ox_sc_saved_image_6?smid=A26YYQ0U8ZSIL1&th=1&fbclid=IwZXh0bgNhZW0CMTAAAR3OHTIsuTVPA87PuMNIWnn7T4jbanqNulj9qqmRlwjzUQN9G-_3_W3q3uY_aem_u01wLl5SsgueUL4NCu3KzA a  ID-COOLING IS-55 BLACK CPU Cooler Low Profile 57mm Height CPU Air Cooler 5 Heatpipes 120x120x15mm Slim Fan, CPU Fan for Intel LGA1700/115X/1200; AMD AM4/AM5 for cooling seems a good pick, but in the case I have had to put 2 fans blowing in. It was 90c+ ganibg. From that cas linked it will suck ait right from outside. They ddid say don't OC with the fan, so just a 5800 may be better. Be so cool to gave a screaming system, the size of a BAI bottle.

[Levent]

AMD Ryzen 7 5800X 8-core, 16-Thread Unlocked Desktop Processor will not have enough cooling in Aluminum Mini ITX Case with PCIe Riser, JOYJOM Mini PC Case, SFF Small Form Factor PC Case, TX Computer Gaming Case supports GPU Graphics Card (Black) with stock PBO.



[Edward78]

2 minutes ago, Levent said:

AMD Ryzen 7 5800X 8-core, 16-Thread Unlocked Desktop Processor will not have enough cooling in Aluminum Mini ITX Case with PCIe Riser, JOYJOM Mini PC Case, SFF Small Form Factor PC Case, TX Computer Gaming Case supports GPU Graphics Card (Black) with stock PBO.



thought so, would be cool to have a screamen sys that small. my old 2700 would prob. be fine in it. What would be the best chip it could take (AMD)? Thought about butcher a old original Xbox & making a frnkencase, putting the inside from that in the Xbox, but that wouldn't work either right.

[venomtail]

16 minutes ago, Levent said:

AMD Ryzen 7 5800X 8-core, 16-Thread Unlocked Desktop Processor will not have enough cooling in Aluminum Mini ITX Case with PCIe Riser, JOYJOM Mini PC Case, SFF Small Form Factor PC Case, TX Computer Gaming Case supports GPU Graphics Card (Black) with stock PBO.

When I need to reach word count minimum on my essay

[PDifolco]

21 minutes ago, Levent said:

AMD Ryzen 7 5800X 8-core, 16-Thread Unlocked Desktop Processor will not have enough cooling in Aluminum Mini ITX Case with PCIe Riser, JOYJOM Mini PC Case, SFF Small Form Factor PC Case, TX Computer Gaming Case supports GPU Graphics Card (Black) with stock PBO.



In eco mode 60W TDP it should be fine imo

[venomtail]

8 minutes ago, PDifolco said:

In eco mode 60W TDP it should be fine imo

Wouldn't it be then just smarter to get the 5700X? No eco modes just standard will run at 65W, probs even faster than a 5800X at reduced power thus speeds even when base 5700X is 5-10% slower.

[Edward78]

7 minutes ago, venomtail said:

Wouldn't it be then just smarter to get the 5700X? No eco modes just standard will run at 65W, probs even faster than a 5800X at reduced power thus speeds even when base 5700X is 5-10% slower.

So that cooler in that small case will be fine, cool.

[Imakuni]

21 minutes ago, venomtail said:

Wouldn't it be then just smarter to get the 5700X? No eco modes just standard will run at 65W, probs even faster than a 5800X at reduced power thus speeds even when base 5700X is 5-10% slower.

They're the same CPU, grab whichever you can snag for cheaper (probably the 5700x, but who knows, maybe someone with good common sense is selling theirs for the same price) and tune it manually to match the use case.

[venomtail]

14 minutes ago, Edward78 said:

So that cooler in that small case will be fine, cool.

That's not what I said at all.

[Levent]

31 minutes ago, PDifolco said:

In eco mode 60W TDP it should be fine imo

yeah hence the "stock pbo"

[Edward78]

16 minutes ago, venomtail said:

That's not what I said at all.

Fine for ECO is what I meant. I want a chip it will cool out of the box though. If a 5700x will be good that is what I want.

[venomtail]

23 minutes ago, Edward78 said:

Fine for ECO is what I meant. I want a chip it will cool out of the box though. If a 5700x will be good that is what I want.

My point was that I'd just buy a 5700X and save the money over a 5800X if I'll be running the 5800X handicapped.



In terms of you saying "fine" hard to say. It'll all depend on how loud the system is. Buy a competent cooler that fits, maybe quiet enough to withstand a full loads noise. Buy a crap one, might still be loud.

[Edward78]

I thought you meant the 5800x, hmmm prob. no way I can have a good CPU in the case & leave the setting alone?


[TVwazhere]

2 hours ago, Edward78 said:

So that cooler in that small case will be fine, cool.

Just a warning that cooler does NOT fit in that case.





For something that small you're looking at a Noctua NH-L9a-AM4 or a thermalright axp90-x36. Aa an owner of the NH-L9a with an R5 3600, I can say for sure the cpu cooler is the loudest part of the system by far. Not to say it's excessively loud



[Edward78]

On 7/18/2024 at 1:00 PM, TVwazhere said:

Just a warning that cooler does NOT fit in that case.





For something that small you're looking at a Noctua NH-L9a-AM4 or a thermalright axp90-x36. Aa an owner of the NH-L9a with an R5 3600, I can say for sure the cpu cooler is the loudest part of the system by far. Not to say it's excessively loud



That sucks, hmmm, what would be a good cooler for monster CPUs.  A case like the Velcxase cases would be good, only yhe gpu would go under the MB, so a AIO could go onto the PSU. You think that would exist already. I wish I new a place that would do a cheap case. I have an idea. All you need to do is have it extent 5.25 past 7 in. get 2 take them down to the frame, extent enough to a SFX to sit dlat, a AIO can sit on the PSU (if it wouldn't get warm from the PSU) & the sandwich can be in the same plasce. Just get the PSU backplate so you can screw it in. Then find some 12 vented panels.

[Edward78]

[2quote]For something that small you're looking at a Noctua NH-L9a-AM4 or a thermalright axp90-x36. Aa an owner of the NH-L9a with an R5 3600, I can say for sure the cpu cooler is the loudest part of the system by far. Not to say it's excessively loud [/quote]



Will those cool a Ryzem 7 2700 well? This GPU will not cuase issues will it? https://www.amazon.com/gp/product/B0C6DWR634/ref=ox_sc_saved_image_4?smid=A18SVRGUWU6QG6&psc=1 sorry for the questions, byt if I do this, I want it to work. Well crap, that GPUs cooler is thicker than the case will support. Ok, this looks like it will work PNY GeForce RTX 3060 12GB XLR8 Gaming Revel Epic-X RGB Single Fan Graphics Card.

[TVwazhere]

22 hours ago, Edward78 said:

Will those cool a Ryzem 7 2700 well? .

I wouldn't say it cools it *well*. It will keep i below TJmax of 95ºC but not by much.

[Edward78]

32 minutes ago, TVwazhere said:

I wouldn't say it cools it *well*. It will keep i below TJmax of 95ºC but not by much.

So the case can't have a food fast CPU?

[tkitch]

2 minutes ago, Edward78 said:

So the case can't have a food fast CPU?

a 36mm heatsink ain't gonna cool something good.  Ever.



There's literally no way to make that work.

[Edward78]

7 minutes ago, tkitch said:

a 36mm heatsink ain't gonna cool something good.  Ever.



There's literally no way to make that work.

Well crap, I found this https://zscases.com/products/a4dc-v2 12 weeks to deliver. If I had a way to extend the where a SFX psu could sit flat with room for a AIO on top, that would work.

[tkitch]

2 minutes ago, Edward78 said:

Well crap, I found this https://zscases.com/products/a4dc-v2 12 weeks to deliver. If I had a way to extend the where a SFX psu could sit flat with room for a AIO on top, that would work.

that can't hold an AIO on top.  the case is less than 200mm deep.



you need to decide:

Do you want a super tiny ITX Case, or do you want an enthusiast build with good cooling?

You can't have both. Because Thermodynamics and Physics.

[Edward78]

4 hours ago, tkitch said:

that can't hold an AIO on top.  the case is less than 200mm deep.



you need to decide:

Do you want a super tiny ITX Case, or do you want an enthusiast build with good cooling?

You can't have both. Because Thermodynamics and Physics.

I was talking about the Joycom having the AIO if I extender the from to 12 hig. sorry I put that in the same post I linked the other, but 12 weeks to get, crap. Wekk this one says it will do 95W TDP, my old Ryzen 7 2700 is 65W https://www.newegg.com/p/13C-004P-00084?fbclid=IwZXh0bgNhZW0CMTAAAR2EiI2sJNS_BrKjJx8yDfAWjv1yzN1fzHiKiilJoUxDfrPNNovET9HdSqY_aem_BIY2IpUijJMSggTpUbzaMw

[Blue4130]

9 hours ago, tkitch said:

that can't hold an AIO on top.  the case is less than 200mm deep.



you need to decide:

Do you want a super tiny ITX Case, or do you want an enthusiast build with good cooling?

You can't have both. Because Thermodynamics and Physics.

You can, but you will need to wear ear protection or suffer going deaf.

[Edward78]

Quote

For something that small you're looking at a Noctua NH-L9a-AM4 or a

thermalright axp90-x36. Aa an owner of the NH-L9a with an R5 3600, I can say for sure the cpu cooler is the loudest part of the system by far. Not to say it's excessively loud



I ordered a 0mm Height Mini-ITX Low Profile Cooler with 92x92x12mm Slim Big Airflow Fan, Black Color Theme, AM4 and LGA115X, TDP 95W for ID-COOLING IS-30. Hopefully it will be enough for the Ryzen 5 2700, that chip is 65w TDP.
