How to know what chords to plug in?

16 minutes ago, slimreaper112 said:

I heard i don't need all of them so how do i know what cables to plug in?



https://pcpartpicker.com/list/6PhDgB  this is my build

Best way to know is to watch a build video, read your manuals, etc.



Unless you need someone to tell you every single cable?



You may also need to know how to connect the motherboard to the case, fans to the motherboard, etc.

"Do what makes the experience better" - in regards to PCs and Life itself.



Onyx AMD Ryzen 7 7800x3d / MSI 6900xt Gaming X Trio / Gigabyte B650 AORUS Pro AX / G. Skill Flare X5 6000CL36 32GB / Samsung 980 1TB x3 / Super Flower Leadex V Platinum Pro 850 / EK-AIO 360 Basic / Fractal Design North XL (black mesh) / AOC AGON 35" 3440x1440 100Hz / Mackie CR5BT / Corsair Virtuoso SE / Cherry MX Board 3.0 / Logitech G502



7800X3D - PBO -30 all cores, 4.90GHz all core, 5.05GHz single core, 18286 C23 multi, 1779 C23 single



Emma : i9 9900K @5.1Ghz - Gigabyte AORUS 1080Ti - Gigabyte AORUS Z370 Gaming 5 - G. Skill Ripjaws V 32GB 3200CL16 - 750 EVO 512GB + 2x 860 EVO 1TB (RAID0) - EVGA SuperNova 650 P2 - Thermaltake Water 3.0 Ultimate 360mm - Fractal Design Define R6 - TP-Link AC1900 PCIe Wifi



Raven: AMD Ryzen 5 5600x3d - ASRock B550M Pro4 - G. Skill Ripjaws V 16GB 3200Mhz - XFX Radeon RX6650XT - Samsung 980 1TB + Crucial MX500 1TB - TP-Link AC600 USB Wifi - Gigabyte GP-P450B PSU -  Cooler Master MasterBox Q300L -  Samsung 27" 1080p



Plex : AMD Ryzen 5 5600 - Gigabyte B550M AORUS Elite AX - G. Skill Ripjaws V 16GB 2400Mhz - MSI 1050Ti 4GB - Crucial P3 Plus 500GB + WD Red NAS 4TBx2 - TP-Link AC1200 PCIe Wifi - EVGA SuperNova 650 P2 - ASUS Prime AP201 - Spectre 24" 1080p



Steam Deck 512GB OLED



OnePlus:

OnePlus 11 5G - 16GB RAM, 256GB NAND, Eternal Green

OnePlus Buds Pro 2 - Eternal Green



Other Tech:

- 2021 Volvo S60 Recharge T8 Polestar Engineered - 415hp/495tq 2.0L 4cyl. turbocharged, supercharged and electrified.

Lenovo 720S Touch 15.6" - i7 7700HQ, 16GB RAM 2400MHz, 512GB NVMe SSD, 1050Ti, 4K touchscreen

MSI GF62 15.6" - i7 7700HQ, 16GB RAM 2400 MHz, 256GB NVMe SSD + 1TB 7200rpm HDD, 1050Ti

- Ubiquiti Amplifi HD mesh wifi



Link to comment
Share on other sites

Link to post
Share on other sites

Which cables in particular are you talking about? Power cables for the motherboard, the GPU or what?



In general you need to provide power to all of the GPUs 6/8 pin connectors.



Your motherboard may be fine with ATX and a single 8 pin, but if it can take an additional 4 pin and the PSU has it, there's no disadvantage to plugging it in.

Remember to either quote or @mention others, so they are notified of your reply

Link to comment
Share on other sites

Link to post
Share on other sites

Honestly just start building it. You don't need to plug them in first. There are times it's easier not to plug them in just from a wire management standpoint. Also inevitably you'll miss something anyways, or need an extra cable anyways because two things are further apart or something.

Link to comment
Share on other sites

Link to post
Share on other sites

27 minutes ago, slimreaper112 said:

I heard i don't need all of them so how do i know what cables to plug in?



https://pcpartpicker.com/list/6PhDgB  this is my build

You mean from power supply or complete? I'll try to make it easier but idk how you gonna connect those nzxt fans without hub.
So here is the list (It might not be a full list since I haven't had a chance to see all components in person.
List:
24 pin connector goes from psu to motherboard

8+4 pin connector for cpu goes from psu to motherboard in the top left corner
Then you have new connector for your gpu (don't know the name) that goes from psu to gpu
As for fans i'm not sure how you'll connect them if you don't have hub. You can connect pwm side of it to different 4pin fan headers on motherboard (if you have enough for all fans), but when it comes to argb stuff, I think they use propriatery connectors...
You can also connect 6pin pcie from power supply to motherboard just under 24 pin port to get more power for pcie slots.
aio pump should be connected to the 4pin AIO Pump header.
As for wiring case usb's, you'll have to figure it out since I can only see type c header which is underneath 6pin pcie header. I assume other usb headers should be beneath usb c one but i'm not sure.
And lastly power and reset buttons are wired on front panel header bottom right on motherboard (it's written on it what goes where).

I'll say again, I'm not sure how you are going to wire rgb stuff. Someone else might help you with that.
I think I didn't miss anything crucial so if you plug all above mentioned correctly you will get a post (assuming you inserted all components properly).

Link to comment
Share on other sites

Link to post
Share on other sites

"Do what makes the experience better" - in regards to PCs and Life itself.



Onyx AMD Ryzen 7 7800x3d / MSI 6900xt Gaming X Trio / Gigabyte B650 AORUS Pro AX / G. Skill Flare X5 6000CL36 32GB / Samsung 980 1TB x3 / Super Flower Leadex V Platinum Pro 850 / EK-AIO 360 Basic / Fractal Design North XL (black mesh) / AOC AGON 35" 3440x1440 100Hz / Mackie CR5BT / Corsair Virtuoso SE / Cherry MX Board 3.0 / Logitech G502



7800X3D - PBO -30 all cores, 4.90GHz all core, 5.05GHz single core, 18286 C23 multi, 1779 C23 single



Emma : i9 9900K @5.1Ghz - Gigabyte AORUS 1080Ti - Gigabyte AORUS Z370 Gaming 5 - G. Skill Ripjaws V 32GB 3200CL16 - 750 EVO 512GB + 2x 860 EVO 1TB (RAID0) - EVGA SuperNova 650 P2 - Thermaltake Water 3.0 Ultimate 360mm - Fractal Design Define R6 - TP-Link AC1900 PCIe Wifi



Raven: AMD Ryzen 5 5600x3d - ASRock B550M Pro4 - G. Skill Ripjaws V 16GB 3200Mhz - XFX Radeon RX6650XT - Samsung 980 1TB + Crucial MX500 1TB - TP-Link AC600 USB Wifi - Gigabyte GP-P450B PSU -  Cooler Master MasterBox Q300L -  Samsung 27" 1080p



Plex : AMD Ryzen 5 5600 - Gigabyte B550M AORUS Elite AX - G. Skill Ripjaws V 16GB 2400Mhz - MSI 1050Ti 4GB - Crucial P3 Plus 500GB + WD Red NAS 4TBx2 - TP-Link AC1200 PCIe Wifi - EVGA SuperNova 650 P2 - ASUS Prime AP201 - Spectre 24" 1080p



Steam Deck 512GB OLED



OnePlus:

OnePlus 11 5G - 16GB RAM, 256GB NAND, Eternal Green

OnePlus Buds Pro 2 - Eternal Green



Other Tech:

- 2021 Volvo S60 Recharge T8 Polestar Engineered - 415hp/495tq 2.0L 4cyl. turbocharged, supercharged and electrified.

Lenovo 720S Touch 15.6" - i7 7700HQ, 16GB RAM 2400MHz, 512GB NVMe SSD, 1050Ti, 4K touchscreen

MSI GF62 15.6" - i7 7700HQ, 16GB RAM 2400 MHz, 256GB NVMe SSD + 1TB 7200rpm HDD, 1050Ti

- Ubiquiti Amplifi HD mesh wifi



Link to comment
Share on other sites

Link to post
Share on other sites

22 hours ago, OhioYJ said:

Honestly just start building it. You don't need to plug them in first. There are times it's easier not to plug them in just from a wire management standpoint. Also inevitably you'll miss something anyways, or need an extra cable anyways because two things are further apart or something.

yeah i think this is the best advice i wanted to use it as a ground so i figured i would do the power supply first, il just plug it in and do the other cables as i go. thanks a ton

Link to comment
Share on other sites

Link to post
Share on other sites

22 hours ago, uzivkovic97 said:

You mean from power supply or complete? I'll try to make it easier but idk how you gonna connect those nzxt fans without hub.
So here is the list (It might not be a full list since I haven't had a chance to see all components in person.
List:
24 pin connector goes from psu to motherboard

8+4 pin connector for cpu goes from psu to motherboard in the top left corner
Then you have new connector for your gpu (don't know the name) that goes from psu to gpu
As for fans i'm not sure how you'll connect them if you don't have hub. You can connect pwm side of it to different 4pin fan headers on motherboard (if you have enough for all fans), but when it comes to argb stuff, I think they use propriatery connectors...
You can also connect 6pin pcie from power supply to motherboard just under 24 pin port to get more power for pcie slots.
aio pump should be connected to the 4pin AIO Pump header.
As for wiring case usb's, you'll have to figure it out since I can only see type c header which is underneath 6pin pcie header. I assume other usb headers should be beneath usb c one but i'm not sure.
And lastly power and reset buttons are wired on front panel header bottom right on motherboard (it's written on it what goes where).

I'll say again, I'm not sure how you are going to wire rgb stuff. Someone else might help you with that.
I think I didn't miss anything crucial so if you plug all above mentioned correctly you will get a post (assuming you inserted all components properly).

i plan on using a fan/rgb controller it holds 6 rgb and 3 fans plus i have some splitters for the rest of the fans thanks for explaining that really strait forward, this is extremely helpful
