What do you use to cool your 8700k?

wolfmanOP
By wolfmanOP
in CPUs, Motherboards, and Memory
 Share
Posted

Curious of your cooling solutions for 8700k or similar CPU.



I want to know your clock speed and average temp after small stress like Cinnebench or something. I recently had to redo my OC and I can't get my chip back up to 5.0ghz stable. I thermal throttle after about 1.34v or so with my H100iV2. Even at like 1.3 or 1.32v I hit upwards of 95c on all cores, which seems really hot running for that chip and cooler.

Link to comment
https://linustechtips.com/topic/1116785-what-do-you-use-to-cool-your-8700k/
Share on other sites
Link to post
Share on other sites
Posted
19 minutes ago, wolfmanOP said:

Curious of your cooling solutions for 8700k or similar CPU.



I want to know your clock speed and average temp after small stress like Cinnebench or something. I recently had to redo my OC and I can't get my chip back up to 5.0ghz stable. I thermal throttle after about 1.34v or so with my H100iV2. Even at like 1.3 or 1.32v I hit upwards of 95c on all cores, which seems really hot running for that chip and cooler.

Something isn't right there. I have a 8700k and I was able to run 5 ghz at 1.300v on my hyper 212 evo.... A 100iv2 is definitely a better solution than my hype 212 was. In Asus Realbench I think I was hitting low to mid 80's....  Is your pump plugged into the CPU's PWM fan header? Are the fans ramping up at all when under load? Something seems very wrong.

Rig: i7 13700k - - Asus Z790-P Wifi - - RTX 4080 - - 4x16GB 6000MHz - - Samsung 990 Pro 2TB NVMe Boot + Main Programs - - Assorted SATA SSD's for Photo Work - - Corsair RM850x - - Sound BlasterX EA-5 - - Corsair XC8 JTC Edition - - Corsair GPU Full Cover GPU Block - - XT45 X-Flow 420 + UT60 280 rads - - EK XRES RGB PWM - - Fractal Define S2 - - DellAlienware AW3423DWF 34" -- Logitech G502 - - Logitech G710+ - - Logitech Z5500 - - LTT Northern Lights Deskpad



Headphones/amp/dac: Schiit Lyr 3 - - Fostex TR-X00 - - Sennheiser HD 6xx



Homelab/ Media Server: Proxmox VE host - - 512 NVMe Samsung 980 RAID Z1 for VM's/Proxmox boot - - Xeon e5 2660 V4- - Supermicro X10SRF-i - - 128 GB ECC 2133 - - 10x4 TB WD Red RAID Z2 - - 45 HomeLab HL15 15 Drive 4U - - Corsair RM650i - - LSI 9305-16i HBA - - TreuNAS + many other VM’s



iPhone 14 Pro - MacBook Air M3

Link to post
Share on other sites
Posted
27 minutes ago, wolfmanOP said:

I want to know your clock speed and average temp after small stress like Cinnebench or something. I recently had to redo my OC and I can't get my chip back up to 5.0ghz stable. I thermal throttle after about 1.34v or so with my H100iV2. Even at like 1.3 or 1.32v I hit upwards of 95c on all cores, which seems really hot running for that chip and cooler.

In Cinebench R15, I am averaging something around ~73C and in R20 something around ~77C. The maximum core-voltage, according to hwinfo64, is 1.33V. I am running all-core 4.9GHz with a Noctua NH-D15S. As for the scores, (I don't know if you wanted to know them or not) I get 1552cb in R15 and 3652cb in R20, though I have a whole bunch of stuff running in the background, since I just couldn't be arsed to close all of my stuff for this.



EDIT: Thought to mention that I didn't win the silicon-lottery; I have to raise voltages way too much to get a stable 5GHz all-core that it's just not worth it. 4.9GHz seems to be the sweet spot for my CPU.

Hand, n. A singular instrument worn at the end of the human arm and commonly thrust into somebody’s pocket.

Link to post
Share on other sites
Posted

Use a custom loop with the fans as low as they can go when running at 4.5.



At 5.0 I turn stuff up but doesn’t seem to help the temps.

Just delidded it today but haven’t done any testing.



Id prolly have a delid and 360 aio at a minimum but over clocking hasn’t got me anything real world.


Main RIg Lian Li O11 MINI, I7 9900k, ASUS ROG Maximus XI Hero, G.Skill Ripjaws 3600 32GB, 3090FE, EVGA 1000G5, Acer Nitro XZ3 2560 x 1440@240hz



Spare RIg Lian Li O11 AIR MINI, I7 4790K, Asus Maximus VI Extreme, G.Skill Ares 2400 32Gb, EVGA 1080ti, 1080sc 1070sc & 1060 SSC, EVGA 850GA, Acer KG251Q 1920x1080@240hz



Link to post
Share on other sites
Posted

Seems weird that you can't even do cinebench with an AIO at 1.3v without hitting 90+



Before I delidded my 8700k was at 1.35v on a Cryorig H7 QL and while it would throttle in a serious stress test, on cinebench it wouldn't get that high.



Make sure your cooler is installed correctly and it's working right

Before you reply to my post, REFRESH. 99.99% chance I edited my post.



My System: i7-13700KF // Corsair iCUE H150i Elite Capellix // MSI MPG Z690 Edge Wifi // 32GB DDR5 G. SKILL RIPJAWS S5 6000 CL32 // Nvidia RTX 4070 Super FE // Corsair 5000D Airflow // Corsair SP120 RGB Pro x7 // Seasonic Focus Plus Gold 850w //1TB ADATA XPG SX8200 Pro/1TB Teamgroup MP33/2TB Seagate 7200RPM Hard Drive // Displays: LG Ultragear 32GP83B x2 // Royal Kludge RK100 // Logitech G Pro X Superlight // Sennheiser DROP PC38x

Link to post
Share on other sites
